Blackout Collection
Total light blockage
Premium motorized shading
SlimLine Wall Switch & Remote Kit
Control where you expect it.
Price on request
Light control
n/a
Mount
Inside mount, outside mount, ceiling mount
Control
Remote, wall switch, app, smart home
Lead time
2-4 weeks
Warranty
10 year motor, 5 year fabric and hardware
- Free sample kit before you commit
- Trade and project pricing on request
- Made to measure to the millimetre
- Ships worldwide with export documentation
Overview
Designed for better motors and controls
The drive and control layer that sits behind every Norvablind shade: tubular motors, hubs, wall switches and remotes, all selected to match the shade type, the window size and the building control system.
Every unit is made to measure and pre-programmed at the factory, so installation is mounting and pairing rather than motor configuration. Fabric, colour and control options are confirmed against a physical sample before production.
Quiet drive
Silent motor options measure under 35 dB in normal operation.
Power flexibility
Battery, AC, or solar, so a scheme can mix power sources per window.
Open protocols
Zigbee, Matter, Wi-Fi, dry contact and RS-485 depending on the hub.
Group and scene control
Shades group by room, facade or scene from a single remote or app.
Key features
Multi-channel wall switch with scene keys
Handheld remote for single or grouped shades
Wall plate matched to switch ranges
Battery free kinetic option
Simple pairing with no tools
Suitable for retrofit
Motors and Controls specification
Motor sizes
25 mm, 28 mm and 35 mm tubular
Torque range
0.8 Nm to 6 Nm
Noise level
35 dB(A) standard, 28 dB(A) silent option
Duty cycle
4 minutes continuous, suitable for commercial cycles
Radio frequency
433 MHz, 868 MHz, 2.4 GHz
Protocols
Zigbee 3.0, Matter, Wi-Fi, dry contact, RS-485
Battery life
Approx. 500 cycles per charge
Ideal for
- Retrofit and new build projects
- Smart home and BMS integration
- High-cycle commercial windows
- Multi-shade single-control schemes
Fabrics and finishes for this product
A curated selection from the Norvablind fabric library. Physical samples are the only reliable way to judge colour and openness, so we ship swatch books at no cost.
Light Filtering
Soft, natural light
Textured Linen Look
A refined, modern texture
Neutral Essentials
Timeless, versatile tones
Dual Layer Banded
Adjustable privacy
Honeycomb Thermal
Insulating cells
Sheer Voile
Diffused daylight
Drapery Weight
Fold and drape
Control options
Choose the control method that suits the space. Several methods can be combined on the same window, and the wall switch always works even with no network.
Remote control
Single or multi channel, with a favourite position key.
Wall switch
Matched to your switch range, with scene keys.
Mobile app
Scenes, schedules and sunrise tracking.
Smart home
Matter, Zigbee, Wi-Fi, dry contact and RS-485.
Installation and support
Everything needed to plan, install and hand over, including the clearances and wiring diagrams that matter on site.
Yes. Alongside remote and app control we offer dry contact and RS-485 interfaces, which is how most commercial BMS and AV control systems integrate shading. Share the control specification and we will confirm the matching interface.
A typical rechargeable pack is rated for around 500 full cycles, which is roughly 12 to 18 months on a twice-daily window. The solar panel option extends this indefinitely in good daylight.
